Name: Dana 3-4-1763-1 1410 Series Drive Shaft End Yoke - Steel, BS Yoke Style, Straight Round Hole
SKU: 3417631
Price: 312.49 USD
Availability: InStock

DANA part description

Series:	1410
Yoke Style:	BS
Hub Diameter (R):	2.252
C/L to End Hub S:	3.700 in.
Type:	Straight Round Hole
Outside Yoke Dimension (E):	4.19 in.
Yoke Bearing Dimension (D):	1.188 in.
Involute Spline:	N
Hole Diameter (P):	1.250 in.
SAE Keyway Width (IN) X:	0.313
Keyway Location W:	12
Length Thru Hole Q:	2.000
Material:	Steel
Keyway Width - Max:	0.3155
Keyway Width - Min:	0.3155

Product Description

Features & Benefits

Uses high-grade Dana approved materials to ensure optimal quality.
Dana designed, tested and engineered.
Genuine OE quality. Tested and proven.

Product Attributes

Series	1410
Material	Steel
Type	Straight Round Hole
Hole Diameter (In) P	1.250 IN
Hub Diameter R	2.252 IN
Involute Spline	N
Length Thru Hole Q	2.000 IN
Outside Yoke Dimension (In) E	4.188 IN
Yoke Bearing Dimension (In) D	1.188 IN
Yoke Style	BS
Keyway Location W	12
Sae Keyway Width (In) X	0.313 IN
C/L To End Hub S	3.700 IN
Keyway Width - Max	0.3155 IN
Keyway Width - Min	0.3155 IN

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	8708990000
Harmonized Tariff Code (HTS)	8708990000
UPC	00023913232603
VMRS Code	024001003

Part Interchanges

Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
