DANA 2-53-1351 Part Description
Manufacturer
Features & Benefits
- Dana manufactured Spicer components are designed, engineered, tested, and manufactured to meet or exceed OE requirements.
- Spicer components are engineered to meet or exceeds the performance requirements of the original factory driveline component
- Tested for unparalleled reliability
- Strength and durability for long life
| For Use With: | END YOKE OR COMPANION FLANGE |
| Spline Outside Diameter: | 1.125 in. |
| Number of Splines: | 26 I |
| Involute: | Y |
| Fits Tube Diameter: | 2.500 |
| Fits Tube Wall: | 0.083 in. |
| Spline End to Brg Shoulder (Y): | 1.906 in. |
| Spline End to Weld (K) In.: | 3.406 |
| Spline Length (L) IN.: | 1.375 |
| Thread Size: | .625-18 |
| Shoulder Diameter (B) In.: | 1.181 |
| Shoulder Length (G) In.: | .665 |
| Bearing Diameter (C) In.: | 1.181 |
| Butt Diameter: | 2.345 |
| Style: | 2 |
| Bearing Diameter (Max): | 1.1815 |
| Bearing Diameter (Min): | 1.181 |
DANA 2-53-1351 Specifications
Product Attributes
| Thread Size | .625-18 IN |
| Style | 2 |
| Fits Tube Diameter | 2.500 IN |
| Number of splines | 26 I |
| Involute | Y |
| Fits Tube Wall | .083 IN |
| Butt Diameter | 2.345 IN |
| Bearing Diameter (C) In. | 1.181 IN |
| Bearing Diameter (Max) | 1.1815 IN |
| Spline End To Weld (K) In. | 3.406 IN |
| Spline Length (L) In. | 1.375 IN |
| Spline O.D. | 1.125 IN |
| Bearing Diameter (Min) | 1.181 IN |
| For Use With | END YOKE OR COMPANION FLANGE |
| Shoulder Diameter (B) In. | 1.181 IN |
| Shoulder Length (G) In. | .665 IN |
| Spline End To Brg Shoulder (y) | 1.906 |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8708990000 |
| Harmonized Tariff Code (HTS) | 8708990000 |
| UPC | 00023913235352 |
| VMRS Code | 024002060 |
DANA 2-53-1351 Part Interchanges
| Brand | Part Number |
|---|---|
| Daimler Truck North America | SP 2 53 1351HP |
| Dana Commercial Vehicle Service Parts | 2-53-1351B250 |
| Volvo | SP 2531351 |
| International Harvester (IHC) | 2531351, D2531351, E2531351 |
| Navistar | 2531351, D2531351, DS2531351, E2531351 |
| Freightliner | SP 2 53 1351HP |
| UAP | 2-53-1351 |
