Name: Dana 2-4-7181-1 1310 Series Drive Shaft End Yoke - Steel, 10 Spline, BS Yoke Style, Splined Hole
SKU: 2471811
Price: 247.99 USD
Availability: InStock

DANA part description

Series:	1310
Spline Count:	10
Yoke Style:	BS
Hub Diameter R:	2.125 in.
C/L to End Hub S:	3.500
Type:	Splined Hole
Outside Yoke Dimension (E):	3.219 in.
Yoke Bearing Dimension (IN) D:	1.062
Major Diameter:	1.500
Involute Spline:	N
Length Thru Hole Q:	1.734
Material:	Steel
Joint Angle #1:	30

Features & Benefits

Uses high-grade Dana approved materials to ensure optimal quality.
Dana designed, tested and engineered.
Genuine OE quality. Tested and proven.

Product Attributes

Series	1310
Material	Steel
Spline Count	10
Type	Splined Hole
Hub Diameter R	2.125 IN
Involute Spline	N
Length Thru Hole Q	1.734 IN
Outside Yoke Dimension (In) E	3.219 IN
Yoke Bearing Dimension (In) D	1.062 IN
Yoke Style	BS
Major Diameter	1.500 IN
C/L To End Hub S	3.500 IN
Joint Angle #1	30

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	8708990000
Harmonized Tariff Code (HTS)	8708990000
UPC	00023913236977
VMRS Code	024001003

Part Interchanges
