Name: Dana 2-28-1717 1330 Series Drive Shaft Tube Weld Yoke - Steel, SR Design, fits 3.500 in. dia. Tube
SKU: 2281717
Price: 39.49 USD
Availability: InStock

DANA part description

Series:	1330
Outside Yoke Dimension (E):	3.875 in.
Bearing Cap Diameter (D):	1.062 in.
Fits Tube Diameter:	3.500 in.
Fits Tube Wall (S=Seam W=Weld):	.083-WELDED
Butt Diameter (F):	2.345 in.
C/L to Weld (H):	1.812 in.
Design:	SR
Material:	Steel
Joint Angle #1:	20

Product Attributes

Series	1330
Material	Steel
Design	SR
Fits Tube Wall (S=Seam W=Weld)	.083-WELDED
Joint Angle #1	20
Butt Diameter (F) In.	2.345 IN
C/L To Weld (H) In.	1.812 IN
Bearing Cap Diameter (D) In.	1.062 IN
Outside Yoke Dimension (E) In.	3.875 IN
Fits Tube Diameter (In)	3.500 IN

Additional Information

Country of Origin (Primary)	US
Harmonized Tariff Code (Schedule B)	8708990000
Harmonized Tariff Code (HTS)	8708990000
UPC	00023913229412
VMRS Code	024002057

Part Interchanges

DANA 2-28-1717 Cross Reference

We have 1 alternatives for the 2-28-1717 by DANA:

MERITOR 133N-28-1717
