DANA part description

Spicer 170-4-1041-1X End Yoke Assembly
170410411X
PLEASE USE THE DANA ONILNE END YOKE CATALOG TO SELECT YOUR PART NUMBERS

170-4-1041-1X
JOINT SERIES:SPL170
D DIMENSION:1.938
E DIMENSION:5.457
YOKE STYLE:Half Round
Q LENGTH THRU HOLE:2.485
R HUB DIAMETER:3.5
S CENTERLINE TO END:5.27
SPLINE COUNT:36 I
SPLINE OD:2.364
NOTES:

Features & Benefits

  • Genuine OE quality. Tested and proven.
  • Built to meet OE standards set by Dana
  • Tested and validated to rigorous OE specifications
  • Latest production upgrades ensure genuine Spicer parts are as good or better than the OE parts they replace

Product Attributes

Series SPL170
Material Steel
Spline Count 36
Type Splined Hole
Assembly Y
Hub Diameter R 3.500 IN
Includes Slinger/Plug Y
Involute Spline Y
Length Thru Hole Q 2.485 IN
Outside Yoke Dimension (In) E 6.456 IN
Yoke Bearing Dimension (In) D 2.166 IN
Yoke Style HR
Major Diameter 2.364 IN
C/L To End Hub S 5.270 IN
C-Bore Depth 0.306 IN

Additional Information

Country of Origin (Primary) MX
Harmonized Tariff Code (Schedule B) 8708990000
Harmonized Tariff Code (HTS) 8708990000
UPC 00023913248017
VMRS Code 022003072

Part Interchanges
