Name: Dana 1-3-18KX Slip Yoke
SKU: 1318kx
Price: 123.99 USD
Availability: InStock

DANA part description

Spicer 1-3-18KX 1110 Series Sleeve
1318KX
PLEASE USE THE DANA ONILNE SLIP YOKE CATALOG TO SELECT YOUR PART NUMBERS

1-3-18KX
Major Diameter:
F DIMENSION:
J DIMENSION:
YOKE STYLE:SNAP RING
YOKE PLUG PART NUMBER:
DUST CAP PART NUMBER:
SPLINE COUNT:
SPLINE OD:

Product Attributes

Series	1100
Material	Steel
Style	SR
Joint Angle #1	30.0
C/L To End Of Spline (J) In.	4.312 IN
C/L To Face Of Plug (F) In.	.938 IN
No. Of Splines	16
Bearing Cap Diameter (D) In.	0.938 IN
Outside Yoke Dimension (E) In.	2.656 IN
Involute	N
Spline O.D.	1.062 IN

Additional Information

Country of Origin (Primary)	US
UPC	00023913232597
VMRS Code	024002038

Part Interchanges

DANA 1-3-18KX Cross Reference

We have 2 alternatives for the 1-3-18KX by DANA:
