Dana 1-2-39 - 1100 Series Drive Shaft Flange Yoke - Steel, 4 Bolt Holes, Square Design
In stock
Our price is so low on this item, we can't list it online!
Call us at (888) 312-8812 to speak with a customer service representative who can quote the price over the phone.
DANA part description
Flange yoke - Series 16
Product Attributes
Series | 1100 |
Material | Steel |
Number of Bolt Holes | 4 |
Design | Square |
Bolt Circle Dia. In. (B) | 2.750 IN |
Bolt Hole Dia. In (B) | .312 - DRILLED IN |
Flange Face To C/L In. (G) | 1.188 IN |
Flange Or Swing Dia. In. (A) | 3.375 IN |
Outside Yoke Dimension In.(E) | 2.656 IN |
Pilot Dia. M=male F=female (c) | 2.250 - MALE |
Yoke Bearing Dimension In. (D) | 0.938 IN |
Joint Angle #1 | 18 |
Additional Information
Country of Origin (Primary) | MX |
Harmonized Tariff Code (Schedule B) | 8708990000 |
Harmonized Tariff Code (HTS) | 8708990000 |
UPC | 00023913232696 |
VMRS Code | 024002016 |
Part Interchanges
- Harman Kardon SPI1-2-39
- New Holland Construction 70658137
- Caterpillar 5E2620
- Caterpillar 5E-2620
- Daimler Truck North America SP 1 2 39
- Daimler Truck North America SP 1 2 39HP
- Dana Commercial Vehicle Service Parts 2104-1239
- Volvo 2104-1239
- Volvo SP 1239
- International Harvester (IHC) 1239
- International Harvester (IHC) D1239
- International Harvester (IHC) E1239
- Navistar 1239
- Navistar D1239
- Navistar DS1239
- Navistar E1239
- New Holland Agriculture 70658137
- Paccar Parts 1/2/1939
- Mack 2104-1239
- Freightliner SP 1 2 39
- Freightliner SP 1 2 39HP
- Peterbilt 11DS2
Dana Holding Corporation® is an internationally known company specializing in drivetrain and e-Propulsion systems. It conceptualizes, manufactures, and supplies energy-management and power- and conveyance solutions for the present-day and future vehicles and trucks. With its over 115 years of industry experience and innovation, and despite several turbulences the automotive and trucking industry has been through, Dana has managed to take the lead in revolutionary technological inventions. Dana Holding Corporation comprises different world-renowned brands catering to various market segments. These include SPICER Drivetrain Systems, VICTOR REINZ Sealing Products, LONG Thermal Products, BREVINI Motion Systems, GRAZIANO High-Performance Transmissions, FAIRFIELD Custom Gears and Drives, and a lot more.
