(888) 312-8812 Login SignupRAYBESTOS 780753R Raybestos R-Line Brake Rotor
$14499
Limited availability at this price!
In Stock
Get it by Monday, Feb 9
RAYBESTOS 780753R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2014-2012 Chrysler 200 Front, 2014-2012 Dodge Avenger Front, 2009-2008 Dodge Caliber Front
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 780753R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.717 IN |
| Center Hole Diameter | 69 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 1.043 IN |
| Discard Thickness | 26.5 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 9.016 IN |
| Inside Diameter | 229 MM |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 4.5 IN |
| Mounting Bolt Hole Diameter | 114.3 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 13.386 IN |
| Outside Diameter | 340 MM |
| Overall Height | 1.717 IN |
| Overall Height | 43.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352778753 |
RAYBESTOS 780753R Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | YH287591 |
| AUTOZONE | 43173, 43173DG, 43173DL |
| BOSCH | 16011487 |
| BRAKEBEST | 16011487, 780753FZN, 780753R, 780753RGS |
| Brembo | 09.E286.11 |
| CENTRIC | 120.63072, 121.63072, 126.63072CSL, 126.63072CSR, 126.63072SL, 126.63072SR, 127.63072CL, 127.63072CR, 127.63072L, 127.63072R, 128.63072L, 128.63072R, 320.63072 |
| CHRYSLER | 04854622AB, 4854622AB |
| Centric Parts | 120.63072, 121.63072, 126.63072CSL, 126.63072CSR, 126.63072SL, 126.63072SR, 127.63072CL, 127.63072CR, 127.63072L, 127.63072R, 128.63072L, 128.63072R, 320.63072 |
| Dura Corp | BR900752 |
| DuraGo | 900752, BR900752 |
| MAGMA PRODUCTS | PMR143072 |
| Qualis | 43173 |
| UAP | R63072 |
| Ultra Brake | 53243 |
| WAGNER BRAKE | BD180309, BD180309E |
| WORLDPARTS | WS1-153058 |
RAYBESTOS 780753R Fits Vehicles
- Dodge Avenger (2012-2014)
- Chrysler 200 (2012-2014)
- Dodge Caliber (2008-2009)
RAYBESTOS 780753R Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 780753R Questions & Answers
No questions yet
Be the first to ask a question about this product!
