PETERSON LIGHTING part description

850A-1 Rectangular LED Amber Rear Turn Signal

Peterson Lighting Rectangular LED Amber Rear Turn Signal

The Peterson Lighting rectangular LED amber rear turn signal is designed to let other truckers and road users know where your truck wants to go. It is also effective at adding a unique and striking look to your rig.

Features & Benefits

  • An 11-diode light that’s built to offer years of reliable service
  • With superior optics and potted, hardwired terminals for maximum durability
  • Operating range is 9 to 32 volts and fits surface-mount cluster pods and 139mm x 91mm grommet hole with 19mm corner radii
  • With sealed lens and housing that meets IP67 ingress level
  • Must be in in horizontal or vertical position to meet FMVSS 108 (USA) & ECE (European) requirements
  • Tested for durability with a 100,000-hour rated operating life
  • Made of durable components to withstand a lot of external pressure

Product Description

LED TURN SIGNAL, RECTANGULAR, REAR ECE, & DOT 6.5' LEADS 5.30"X3.44" MV

Features & Benefits

  • 11 diodes.
  • Hardwired design.
  • Multivolt version available.
  • Voltage Regulated.
  • ECE & DOT compliant.
  • Certified to meet both FMVSS 108 (USA) & ECE (European) requirements for rear turn signal in horizontal or vertical position.
  • Certified to meet ECE requirements in horizontal or vertical position.
  • Available with 12" or 2 meter (6ó-ft.) hardwired leads.
  • 9–32 volt operating range.
  • Sealed lens and housing meets IP67 ingress protection level.
  • Hardwired design eliminates the need for separate plug and reduces connection points.
  • Multi-volt design is compatible with both 12 and 24 volt systems.
  • 850A has 6.5' leads, others have 300mm (11.8") leads.
  • Potted, hardwired terminals for durability.
  • 850A-1P has hardwired PL3 plug.
  • 850A-1P has hardwired PL3 plug. Others have stripped leads.
  • Grommet fits material up to 6 mm.
  • Matching red stop/turn/tail light on Peterson Master Catalog page 16.
  • Also fits surface-mount cluster pods. See Peterson Master Catalog page 189.
  • Matching white back-up light on Peterson Master Catalog page 99.

850-18: rubber grommet (poly pack - std qty 12)

Product Attributes

Length 5.3 IN
Width 1.34 IN
Height 3.52 IN
Bulb Technology LED
Bulb/diode Count 11
California Proposition 65 Required Y
Container Type bulk pack
Family PM
Integral Reflex N
Lens Color amber
Light Color amber
Marine Use Y
Maximum Voltage 32 Volts
Minimum Voltage 9 Volts
Mounting Type grommet
Multi-volt Y
Regulatory Compliance DOT + ECE
Shape rectangular
Termination stripped wire
Voltage 12 Volts

Additional Information

Country of Origin (Primary) TW
Harmonized Tariff Code (Schedule B) 8512204000
UPC 00044464981901
VMRS Code 034003194

Peterson Lighting® is a family-owned company that produces and distributes vehicle safety lighting systems mirrors, and other related safety products and accessories. It has been in the business for 75 years, and currently, it offers over 2,200 products designed for various applications, including tilt-bed and cargo vehicles and light- and medium-duty trailers. Peterson Lighting believes that full commitment to quality is its responsibility as a market leader. All its components are designed and manufactured only in its ISO 9001/QS-9000-certified facility in Grandview, MO. This facility is handled by knowledgeable and highly skilled specialists, who are as dedicated and passionate as the company when it comes to quality.
