Delphi TA3302 - Tie Rod End
$2799
In stock
limited availability at this price!
. Learn more
DELPHI part description
Product Description
Tie Rod End
Product Attributes
| Length | 230.50 MM |
| Color | Black |
| Shank Length | 15.60 MM |
| End 1 Gender | Female |
| End 2 Gender | Male |
| Stud Length | 15.60 MM |
| Finish | Painted |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Width | 59 MM |
| Type | Bent |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 14.00 MM |
| Height | 94.80 MM |
| Grade Type | Standard |
| Housing Material | Steel |
| 36 | 0.880 IN |
| Adjustable | No |
| Greasable | No |
| Boot Color | Black |
| Weight | 0.88 lb |
| Cone Outside Diameter | 15.60 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Grade | Premium |
| Stud Type | Threaded |
| End 2 Thread Pitch | 1.5 MM |
| End 1 Thread Pitch | 1.5 MM |
| Length Stud Center to End | 209.50 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 16.00 MM |
| Position(s) | Left Outer |
| Shank Length | 0.614 IN |
| Stud Length | 0.614 IN |
| End 2 Thread Diameter | 0.551 IN |
| Tube Diameter | 22.50 MM |
| 662 | 0.614 IN |
| Length Stud Center to End | 8.248 IN |
| End 1 Thread Diameter | 0.630 IN |
Additional Information
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (Schedule B) | 8708948000 |
| Harmonized Tariff Code (HTS) | 8708947550 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604393987 |
| VMRS Code | 015004020 |
| UNSPSC | 25174205 |
Part Interchanges
Fits Vehicles
- Audi SQ5 Sportback (2021-2022)
- Audi Q5 Sportback (2021-2022)
- Audi RS7 Sportback (2021-2022)
- Audi RS6 Avant (2021-2022)
- Audi Q5 PHEV (2020-2022)
- Audi S7 Sportback (2020-2022)
- Audi A6 allroad (2020-2022)
- Audi S6 (2020-2022)
- Audi A7 Sportback (2019-2022)
- Audi A6 Quattro (2019-2022)
- Audi RS5 Sportback (2019, 2021-2022)
- Audi S5 Sportback (2018-2022)
- Audi A5 Sportback (2018-2022)
- Audi A5 Quattro (2018-2022)
- Audi RS5 (2018-2019, 2021-2022)
- Audi S5 (2018-2022)
- Audi SQ5 (2018-2022)
- Audi Q5 (2018-2022)
- Audi S4 (2018-2022)
- Audi A4 allroad (2017-2022)
- Audi A4 Quattro (2017-2022)
- Audi A4 (2017-2020)
Delphi® is committed to making a difference. With a global network of more than 2,400 service centers and a presence in over 150 countries, Delphi Technologies delivers OE-specific aftermarket parts and software solutions for a wide range of passenger vehicles, light and medium commercial vehicles, heavy-duty truck and commercial vehicles, as well as agricultural, marine, and industrial equipment. The company’s comprehensive product portfolio includes components for diesel fuel systems, engine management, gasoline fuel systems, vehicle electronics, and maintenance solutions. Delphi Technologies takes pride in its state-of-the-art manufacturing facility as well as OE-level diagnostic and test equipment that produces OE-quality aftermarket components to make vehicles and trucks run cleaner, drive better, and last further.
