Name: A-1 Cardone 73-6782F Body Control Computer
SKU: 736782f
Price: 148.99 USD
Availability: InStock

A-1 CARDONE part description

Body Control Computer

Product Description

Body Control Computer

Application Summary

Buick Rainier 2007-04; Chevrolet Trailblazer 2009-02, Trailblazer EXT 2006-02; GMC Envoy 2009-02, Envoy XL 2006-02, Envoy XUV 2005-04; Isuzu Ascender 2008-03; Oldsmobile Bravada 2004-02; Saab 9-7x 2008-05

Features & Benefits

100% re-soldering of critical components ensures superior electrical connections, prevents intermittent failures and extends product life.
All modules are 100% tested with automated computerized test equipment to ensure functionality and reliability.
Each unit comes loaded with the latest O.E. software calibration available, where applicable.
On-car validation routines ensure that modules meet all form, fit, durability and performance requirements.
As a remanufactured Original Equipment part, this unit guarantees a perfect vehicle fit.
Our remanufacturing process is earth-friendly, as it reduces the energy and raw material needed to make a new part by 80%.

Body Control Computer, BCC, BCM, Body Control Module, Computer, Module, GEM, GEM Module

Product Attributes

Terminal Quantity	21
Product Condition	Remanufactured
Mounting Hole Quantity	4
Housing Color	Black
Removable Prom	No
Connector Quantity	3
E-waste	Yes
Connector Shape	Rectangle
Terminal Gender	Male
Housing Length (in)	6.93
Housing Width (in)	4.8
Features and Benefits	Our remanufacturing process is earth-friendly, as it reduces the energy and raw material needed to make a new part by 80%.
Flash Programming Required	Yes
Flashable	Yes
Housing Height (In)	2.25
Connector Color	Black
Connector Gender	Male
Connector Quantity	3
Connector Shape	Rectangular
Flash Programming Required	No
Flashable	No
Housing Color	Black
Housing Height	2.25 IN
3730	57.15 MM
Housing Length	175.9 MM
Housing Length	6.925 IN
Housing Material	Plastic
Housing Width	121.92 MM
Housing Width	4.8 IN
Mounting Hole Quantity	4
Mounting Type	Bolt on
Programming Required	No
Removable PROM	No
Terminal Gender	Male
Terminal Quantity	21
Terminal Type	Blade Pin
Bolt on Mounting	Yes
Is Item A Chemical	No
Package Contents	Module; Instruction Sheet
Contains Electronic Components	Circuit Board
Does it require SDS	No
Is Or Contains A Battery	No
Is Or Contains A Bulb	No
Is Prop Sixty Five Affected	No
Is the item CARB affected	No
FAQ_Q1	What is a Body Control Module (BCM)?
FAA_A1	A body control module is an electronic control unit that monitors and controls various electronic accessories throughout the body of the vehicle.
FAQ_Q2	Are there different types of BCMs?
FAA_A2	Yes, there are several different types of BCMs. The BCM controls the main functions of the body; however there are some BCM types that have body control functions but were given different names because they may also include other specific functions. For example, Ford vehicles have central timer, general electronic and lighting control modules. Chrysler uses both “body control module” and “totally integrated power module” to describe their BCMs. GM has always called their BCM a “body control module.”
FAQ_Q3	What does a BCM control?
FAA_A3	BCMs control power accessories, courtesy lighting, central locking, remote keyless entry, passive start and entry, tire pressure monitoring and immobilizer systems.
FAQ_Q4	Do I need special tools to install the replacement BCM?
FAA_A4	Some BCMs require special tools to meet programming, relearn and installation requirements while others are plug and play and do not have any special installation procedures or requirements. The best practice when installing a BCM is to refer to a vehicle specific service manual for d proper module replacement procedures.
FAQ_Q5	Does the replacement BCM need programming?
FAA_A5	Most BCMs need to be programmed by the remanufacturer or a shop equipped with the proper tools. If the replacement BCM needs programming, it must be programmed with the latest operating software and vehicle calibrations. Failure to do so may result in a no-start situation or cause certain vehicle functions to operate incorrectly. The best practice when installing a BCM is to refer to a vehicle specific service manual for proper module replacement procedures.
FAQ_Q6	Does the BCM communicate with other modules?
FAA_A6	The BCM may communicate with other modules over a variety of protocols or buses, depending on the vehicle. There may be some other modules that a BCM interacts with over a local network for simpler functions. Some types of BCMs interact with other modules over several different protocols (Example: totally integrated power modules).
FAQ_Q7	Is the BCM part of the anti-theft system?
FAA_A7	The BCM is often part of an anti-theft / immobilizer system. Some vehicles have separate modules for theft-deterrent and immobilizer functions.

Additional Information

Remanufactured Part	Y
Warranty Distance	18000
Warranty Distance UOM	DH
Warranty Special UOM	TX
Warranty Time	12
Warranty Time UOM	MO
Country of Origin (Primary)	US
Canadian Harmonizing Tariff Code	8543700000
Harmonized Tariff Code (Schedule B)	8543709665
Harmonized Tariff Code (HTS)	8543709860
UPC	00082617917421

Part Interchanges

Fits Vehicles

Saab 9-7x (2005-2008)
Oldsmobile Bravada (2002-2004)
Isuzu Ascender (2003-2008)
GMC Envoy XUV (2004-2005)
GMC Envoy XL (2002-2006)
GMC Envoy (2002-2009)
Chevrolet Trailblazer EXT (2002-2006)
Chevrolet Trailblazer (2002-2009)
Buick Rainier (2004-2007)
