Name: Weatherhead H42504-250R Nitrile Crimped Hydraulic Hose
SKU: h42504250r
Price: 1196.09 USD
Availability: OutOfStock

WEATHERHEAD part description

Technical Specifications

Item Hydraulic Hose
Type Crimped
Hose Inside Dia. (In.) 1/4
Hose Length (Ft.) 250
Hose Outside Dia. (In.) 1-5/32
Operating Pressure (PSI) 5000
Safety Factor 4:1
Min. Bend Radius (In.) 4

Tube Material Nitrile
Cover Material Neoprene
Reinforcement (2) Steel Braid
Dash Size 04
Temp. Range (F) -40 Degrees to 212 Degrees
Standards SAE 100R2 Type AT
Application Hydraulics

Eaton Weatherhead Hydraulic Hose

The Eaton Weatherhead hydraulic hose is made from premium-quality materials and using advanced manufacturing technology to offer excellent abrasion and chemical resistance. It delivers the flexibility and durability needed in various operating conditions and under the most demanding applications.

Features & Benefits

High-quality nitrile-crimped hydraulic hose with neoprene cover
Works well under -40 Degrees to 212 Degrees F temperature range
Stands up to chemical attacks and ensures a leak-free hose assembly
Compliant to all applicable industry requirements

WEATHERHEAD H42504-250R Cross Reference

We have 1 alternatives for the H42504-250R by WEATHERHEAD:

WHH42504250R

Officially acquired by Eaton in 2002, Weatherhead® is one of the industry’s biggest suppliers of hydraulic hose, hose ends, tube fittings, couplings, assembly equipment, and support accessories. Weatherhead crafts top-products that are widely used in mining, agriculture, construction, truck, and bus applications. Eaton delivers Weatherhead thermoplastic tubing in different sizes—from 1/8 to 1 inch—designed for use in air tools, robotics, beverage dispensing as well as air and water supply. Driven by the company’s goal to offer unique solutions to a wide range of markets that enable businesses to be at the forefront of change, Weatherhead remains the truck industry’s leading source of premium-quality hoses, fittings, and adapters for your fleet’s hose and fittings needs
