Name: Raybestos 580263 Raybestos Specialty - Truck Brake Rotor
SKU: 580263
Price: 253.49 USD
Availability: InStock

RAYBESTOS part description

Product Description

Raybestos Specialty - Truck Brake Rotor

Application Summary

2018-1999 Blue Bird All American FE Front, 2018-2005 Hino 268 Front, 2018-2005 Hino 268 Rear, 2018-2004 Blue Bird Vision School Bus Front, 2009-2003 GMC C5500 Topkick Front, 2009-2003 GMC C5500 Topkick Rear, 2017-2006 Hino 258 Front

Product Attributes

ABS Tone Ring Included	Yes
Center Hole Diameter	6 IN
Center Hole Diameter	152.4 MM
9565	Conventional
Discard Thickness	1.419 IN
Discard Thickness	36.05 MM
Harmonize Code	8708.30.5030
Mounting Bolt Hole Circle Diameter	7.25 IN
Mounting Bolt Hole Circle Diameter	184.15 MM
Mounting Bolt Hole Quantity	10
Nominal Thickness	1.541 IN
Nominal Thickness	39.15 MM
Outside Diameter	15.376 IN
Outside Diameter	390.55 MM
Overall Height	3.403 IN
Overall Height	86.45 MM
Salability Restrictions	No
Solid Or Vented Type Rotor	Vented
Stud/Lug Hole Quantity	10
UNSPSC Code	25171715

Additional Information

Country of Origin (Primary)	CN
UPC	00829352410103

Part Interchanges

RAYBESTOS 580263 Cross Reference

We have 30 alternatives for the 580263 by RAYBESTOS:

Fits Vehicles

Freightliner FL70 (1998-2005)
Freightliner FL60 (1998-2005)
Freightliner FL50 (1998-2005)
Fleetwood Bounder (2010)
Workhorse Custom Chassis W62 (2007-2012)
Workhorse W62 (2007-2011)
Hino 258 (2006-2017)
Blue Bird Vision School Bus (2004-2018)
Blue Bird All American FE (1999-2018)
Workhorse Custom Chassis W24 (2004-2005, 2007-2009, 2011)
Workhorse Custom Chassis R26 (2007-2008)
Blue Bird TC1000 (1998-2000)
Blue Bird TC2000 (1989-2004)
Isuzu HVR (2005-2008)
Isuzu HTR (2005-2008)
Isuzu FVR (2003-2009)
Isuzu FTR (2003-2011)
Workhorse W24 (2004-2009)
Workhorse W25 (2005-2009)
Workhorse R26 (2007-2009)
GMC T7500 (2004-2009)
GMC T6500 (2004-2009)
Chevrolet T7500 (2004-2009)
Chevrolet T6500 (2004-2009)
Hino 308 (2005-2008)
Hino 258LP (2006-2014)
Hino 268 (2005-2018)
Hino 238 (2005-2014)
GMC C5500 Topkick (2003-2009)
GMC C7500 Topkick (2003-2009)
GMC C6500 Topkick (2003-2009)
Chevrolet C7500 Kodiak (2003-2009)
Chevrolet C5500 Kodiak (2003-2009)
Chevrolet C6500 Kodiak (2003-2009)
Chevrolet C4500 Kodiak (2003-2009)
GMC C4500 Topkick (2003-2009)
