(888) 312-8812 Login SignupRAYBESTOS 96784R Raybestos R-Line Brake Rotor
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 96784R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
1986 Porsche 944 Rear, 1995-1993,1991-1986 Porsche 928 Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 96784R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 4.055 IN |
| Center Hole Diameter | 103 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.866 IN |
| Discard Thickness | 22 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5.118 IN |
| Mounting Bolt Hole Circle Diameter | 130 MM |
| Mounting Bolt Hole Diameter | 0.6 IN |
| Mounting Bolt Hole Diameter | 15.25 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24 MM |
| Outside Diameter | 11.772 IN |
| Outside Diameter | 299 MM |
| Overall Height | 2.795 IN |
| Overall Height | 71 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352466698 |
RAYBESTOS 96784R Cross References
| Brand | Part Number |
|---|---|
| ASH12203, 829352466698 | |
| ADVANCE AUTO PARTS | 145369, YH145369 |
| AMERICAN REMANUFACTURED | 89-82024 |
| AUTOZONE | 34160, 34160DG |
| BECK/ARNLEY | 083-2326 |
| BENDIX | 145369 |
| BOSCH | 42011141 |
| BRAKEBEST | 42011141, 96784, 96784R, 96784RGS |
| BrakeBest | 66785RGS, 66786RGS, 76787RGS |
| CENTRIC | 120.37022, 121.37022, 126.37022CSL, 126.37022CSR, 126.37022SL, 126.37022SR |
| Casting Numbers | 325906 |
| Centric Parts | 120.37022, 121.37022, 126.37022CSL, 126.37022CSR, 126.37022SL, 126.37022SR |
| DURA CORP | BR34160 |
| DuraGo | BR34160 |
| MIGHTY DISTRIBUTING SYSTEM | 34160 |
| NEWTEK AUTOMOTIVE | 34160 |
| Newtek Automotive USA | 34160 |
| Qualis | 34090 |
| UAP | 34160 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X51443 |
| VOLKSWAGEN | 95135204101 |
RAYBESTOS 96784R Fits Vehicles
- Porsche 944 (1986)
- Porsche 928 (1986-1991, 1993-1995)
