Raybestos 580063R - Raybestos R-Line Brake Rotor
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
RAYBESTOS part description
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2004 Pontiac GTO Rear
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.76 IN |
| Center Hole Diameter | 70.1 MM |
| 9565 | Drum-In-Hat |
| Discard Thickness | 0.591 IN |
| Discard Thickness | 15 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM |
| Mounting Bolt Hole Diameter | 0.504 IN |
| Mounting Bolt Hole Diameter | 12.8 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.63 IN |
| Nominal Thickness | 16 MM |
| Outside Diameter | 11.25 IN |
| Outside Diameter | 285.75 MM |
| Overall Height | 3.095 IN |
| Overall Height | 78.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 00829352465165 |
Part Interchanges
- General Motors 92057140
- General Motors 92156689
- Bosch 25010695
- Brembo 27334
- Mighty Distributing System 55089
- Wagner Brake BD126188
- ACDelco 177-0968
- Bendix 145427
- Autospecialty AR8279
- VIPAR - Vehicle Indusrty Parts & Manufacturing X51545
- BrakeBest 25010695
- BrakeBest 580063
- BrakeBest 580063R
- BrakeBest 580063RGS
- BrakeBest BD126188
- Centric Parts 120.62080
- Centric Parts 121.62080
- Centric Parts 125.62080
- Centric Parts 126.62080CSL
- Centric Parts 126.62080CSR
- Centric Parts 126.62080SL
- Centric Parts 126.62080SR
- Centric Parts 127.62080CL
- Centric Parts 127.62080CR
- Centric Parts 127.62080L
- Centric Parts 127.62080R
- Centric Parts 128.62080CL
- Centric Parts 128.62080CR
- Centric Parts 128.62080L
- Centric Parts 128.62080R
- AutoZone 55089
- Advance Auto Parts 145427
- Advance Auto Parts YH145427
- Casting Numbers 211456-C
- Casting Numbers 325971
- Dura Corp BR55089
- Qualis 55089
- Newtek Automotive USA 55089
- TRW DF7014S
- TRW DF7500S
- Promax 14-55089
- UAP 55089
- NAPA BRAKES TSR040
- NAPA BRAKES TSR041
- DuraGo BR55089
RAYBESTOS 580063R Cross Reference
We have 42 alternatives for the 580063R by RAYBESTOS:
- ACDELCO 177-0968
- AUTOSPECIALTY AR8279
- BENDIX 145427
- BOSCH 25010695
- GM 92057140
- GM 92156689
- ADVANCE AUTO PARTS 145427
- ADVANCE AUTO PARTS YH145427
- AUTOZONE 55089
- BRAKEBEST 25010695
- BRAKEBEST 580063
- BRAKEBEST 580063R
- BRAKEBEST 580063RGS
- BRAKEBEST BD126188
- BREMBO 27334
- CENTRIC 120.62080
- CENTRIC 121.62080
- CENTRIC 125.62080
- CENTRIC 126.62080CSL
- CENTRIC 126.62080CSR
- CENTRIC 126.62080SL
- CENTRIC 126.62080SR
- CENTRIC 127.62080CL
- CENTRIC 127.62080CR
- CENTRIC 127.62080L
- CENTRIC 127.62080R
- CENTRIC 128.62080CL
- CENTRIC 128.62080CR
- CENTRIC 128.62080L
- CENTRIC 128.62080R
- DURA CORP BR55089
- MIGHTY DISTRIBUTING SYSTEM 55089
- NAPA BRAKES TSR040
- NAPA BRAKES TSR041
- NEWTEK AUTOMOTIVE 55089
- PROMAX 14-55089
- QUALIS 55089
- TRW DF7014S
- TRW DF7500S
- UAP 55089
- VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING X51545
- WAGNER BRAKE BD126188
Fits Vehicles
- Pontiac GTO (2004)
