Name: Raybestos 96617 Raybestos Specialty - Street Performance Brake Rotor
SKU: 96617
Price: 40.49 USD
Availability: InStock

RAYBESTOS part description

Product Description

Raybestos Specialty - Street Performance Brake Rotor

Application Summary

2006-1996 Hyundai Elantra Rear, 2001-1997 Hyundai Tiburon Rear

Product Attributes

ABS Tone Ring Included	No
Center Hole Diameter	2.99 IN
Center Hole Diameter	75.95 MM
9565	Conventional
9540	Non-Directional
Discard Thickness	0.315 IN
Discard Thickness	8 MM
Harmonize Code	8708.30.5030
Material	Cast Iron
Mounting Bolt Hole Circle Diameter	4.5 IN
Mounting Bolt Hole Circle Diameter	114.3 MM
Mounting Bolt Hole Diameter	0.498 IN
Mounting Bolt Hole Diameter	12.65 MM
Mounting Bolt Hole Quantity	4
Nominal Thickness	0.395 IN
Nominal Thickness	10.05 MM
Outside Diameter	10.16 IN
Outside Diameter	258.05 MM
Overall Height	1.59 IN
Overall Height	40.4 MM
Salability Restrictions	No
Solid Or Vented Type Rotor	Solid
Stud/Lug Hole Quantity	4
UNSPSC Code	25171715

Additional Information

Country of Origin (Primary)	CN
UPC	00747730048376

Part Interchanges

RAYBESTOS 96617 Cross Reference

We have 63 alternatives for the 96617 by RAYBESTOS:

Fits Vehicles

Hyundai Tiburon (1997-2001)
Hyundai Elantra (1996-2006)
