(888) 312-8812 Login SignupRAYBESTOS 76002R Raybestos R-Line Brake Rotor
MSRP: $55.91
$4299
Save $12.92
Limited availability at this price!
In Stock
Get it by Friday, Feb 6
RAYBESTOS 76002R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
1995-1989 Chrysler LeBaron Rear, 1995-1990 Plymouth Acclaim Rear, 1995-1990 Dodge Spirit Rear, 1993-1990 Chrysler New Yorker Rear, 1993-1990 Dodge Dynasty Rear, 1994-1993,1991-1989 Dodge Shadow Rear, 1993-1989 Dodge Daytona Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 76002R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.262 IN |
| Center Hole Diameter | 57.45 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.409 IN |
| Discard Thickness | 10.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Mounting Bolt Hole Circle Diameter | 100 MM |
| Mounting Bolt Hole Diameter | 3.937 IN |
| Mounting Bolt Hole Diameter | 100 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.472 IN |
| Nominal Thickness | 12 MM |
| Outside Diameter | 10.635 IN |
| Outside Diameter | 270.15 MM |
| Overall Height | 2.03 IN |
| Overall Height | 51.55 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352366646 |
RAYBESTOS 76002R Cross References
| Brand | Part Number |
|---|---|
| 8MR3005C, 829352366646 | |
| ADVANCE AUTO PARTS | 141532, YH141532 |
| AMERICAN REMANUFACTURED | 789-32029, 89-32029 |
| AUTOPART INTERNATIONAL | 25615 |
| AUTOSPECIALTY | AR8329, AR8329E |
| AUTOZONE | 5345, DL5345 |
| BENDIX | 141532 |
| BRAKE HEADQUARTERS | BR53450 |
| BRAKE PRO | 4616002, 4617002 |
| BRAKEBEST | 76002, 76002R, 76002RGS, BD61948 |
| BREMBO | 08.8819.85, 27206 |
| CALIFORNIA DRUM & ROTOR | 61948 |
| CENTRIC | 120.63029, 121.63029 |
| CENTURY | 7041 |
| CHRYSLER | 04383551, 4383551 |
| CONTINENTAL-CONTITECH | CW12708 |
| Casting Numbers | 210429-C, 325163, 53451, 637041 |
| Centric Parts | 120.63029, 121.63029 |
| DELPHI | RB244 |
| DURA CORP | BR5345 |
| DuraGo | BR5345 |
| EIS BRAKES | D17360 |
| EUROROTOR | 5345 |
| GREN | 601601 |
| GUARDIAN | 52-61948 |
| MCI | 6049, 6075 |
| MIDAS | BR1605 |
| MIGHTY DISTRIBUTING SYSTEM | 5345 |
| NAPA BRAKES | SDK6322 |
| NEWTEK AUTOMOTIVE | 5345 |
| Newtek Automotive USA | 5345 |
| PARTS MASTER | P61948 |
| PROMAX | 14-5345 |
| QUALIS | 5345 |
| QUALITY BRAND | 5345 |
| ROADMATES | 526132 |
| ROCKHILL | 5345 |
| STANDARD ROTORS AND DRUMS | 5345 |
| THE UNIVERSAL GROUP | 103450 |
| UAP | 5345 |
| Universal | 103450 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50552 |
| WAGNER | BD61948 |
| WAGNER BRAKE | BD61948 |
| WINHERE | 441111, YH1111 |
RAYBESTOS 76002R Fits Vehicles
- Pontiac 6000 (1989)
- Chrysler Dynasty (1990-1993)
- Chrysler Daytona (1989-1993)
- Plymouth Sundance (1989-1991, 1993-1994)
- Plymouth Acclaim (1990-1995)
- Dodge Spirit (1990-1995)
- Dodge Shadow (1989-1991, 1993-1994)
- Dodge Dynasty (1990-1993)
- Dodge Daytona (1989-1993)
- Chrysler New Yorker (1990-1993)
- Chrysler LeBaron (1989-1995)
- Chrysler Imperial (1990-1993)
