Name: Raybestos 96503R Raybestos R-Line Brake Rotor
SKU: 96503r
Price: 34.99 USD
Availability: InStock

RAYBESTOS part description

Product Description

Raybestos R-Line Brake Rotor

Application Summary

2003-2001 Toyota Highlander Rear, 1996-1992 Toyota Camry Rear, 2002-1999 Lexus RX300 Rear, 1996-1992 Lexus ES300 Rear

Product Attributes

ABS Tone Ring Included	No
Center Hole Diameter	2.44 IN
Center Hole Diameter	62 MM
9565	Drum-In-Hat
9540	Non-Directional
Discard Thickness	0.354 IN
Discard Thickness	9 MM
Harmonize Code	8708.30.5030
Material	Cast Iron
Mounting Bolt Hole Circle Diameter	4.5 IN
Mounting Bolt Hole Circle Diameter	114.3 MM
Mounting Bolt Hole Diameter	0.575 IN
Mounting Bolt Hole Diameter	14.6 MM
Mounting Bolt Hole Quantity	5
Nominal Thickness	0.39 IN
Nominal Thickness	9.9 MM
Outside Diameter	11.33 IN
Outside Diameter	287.8 MM
Overall Height	2.56 IN
Overall Height	65 MM
Salability Restrictions	No
Solid Or Vented Type Rotor	Solid
Stud/Lug Hole Quantity	5
UNSPSC Code	25171715

Additional Information

Country of Origin (Primary)	CN
UPC	00829352371527

Part Interchanges

RAYBESTOS 96503R Cross Reference

We have 67 alternatives for the 96503R by RAYBESTOS:

Fits Vehicles

Toyota Camry (1992-1996)
Toyota Highlander (2001-2003)
Lexus RX300 (1999-2002)
Lexus ES300 (1992-1996)
