RAYBESTOS part description

Product Description

Raybestos R-Line Brake Rotor

Application Summary

1983-1977 Renault LeCar Front, 1979-1972 Renault R17 Front, 1979-1972 Renault R17 Rear, 1977-1971 Renault R12 Front, 1975-1971 Renault R12 Rear, 1975-1972 Renault R15 Front, 1975-1972 Renault R15 Rear, 1983-1976 Renault R5 Front

Product Attributes

ABS Tone Ring Included No
Center Hole Diameter 3.266 IN
Center Hole Diameter 82.95 MM
9565 Conventional
Discard Thickness 0.354 IN
Discard Thickness 9 MM
Harmonize Code 8708.30.5030
Mounting Bolt Hole Circle Diameter 3.898 IN
Mounting Bolt Hole Circle Diameter 99 MM
Mounting Bolt Hole Diameter 3.898 IN
Mounting Bolt Hole Diameter 99 MM
Mounting Bolt Hole Quantity 6
Nominal Thickness 0.394 IN
Nominal Thickness 10 MM
Outside Diameter 8.976 IN
Outside Diameter 228 MM
Overall Height 1.516 IN
Overall Height 38.5 MM
Salability Restrictions No
Solid Or Vented Type Rotor Solid
Stud/Lug Hole Quantity 6
UNSPSC Code 25171715

Additional Information

Country of Origin (Primary) CN
UPC 00829352465684

Part Interchanges

Fits Vehicles

  • Renault R5 (1976-1983)
  • Renault R17 (1972-1979)
  • Renault R15 (1972-1975)
  • Renault R12 (1971-1977)
  • Renault LeCar (1977-1983)
