*Representative image - actual part not displayed
Centric 130.46528 - Centric Premium Brake Master Cylinder
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
Product Attributes
| Push Rod: Length / Depth [cntrc] In | 1.01 |
| Boss, Nipple Or Port: Bottom [cntrc] | M16-1.00 |
| Weight [cntrc] Lbs | 2.2 |
| Primary Outlet Flare Type [cntrc] | Bubble |
| Product Grade [cntrc] | Premium |
| Publication Bore [cntrc] | 1 1/16" |
| Boss, Nipple Or Port: Front, Top [cntrc] | M10-1.00 bbl |
| Boss, Nipple Or Port: Rear: #a [cntrc] | M10-1.00 bbl |
| Weight [cntrc] Kgs | 1 |
| Secondary Outlet Flare Type [cntrc] | Open |
| Reservoir Material | Plastic |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 26.988 MM |
| Master Cylinder Bore Diameter | 1.063 IN |
| Brake Booster Included | No |
| Master Cylinder Cap Included | Yes |
| Master Cylinder Material | Aluminum |
| Pushrod Included | No |
| Reservoir Included | Yes |
| Reservoir Type | Single |
| Primary Outlet Thread Diameter | 10.000 MM |
| Secondary Outlet Thread Diameter | 16.000 MM |
| Bleeder Hoses Included | No |
| Port Quantity | 4 |
| Mounting Bracket Included | No |
| Secondary Outlet Thread Pitch | 1.00 MM |
| Primary Outlet Thread Pitch | 1.00 MM |
| Bore Type | Straight |
| 9425 | 26.988 MM |
| 9425 | 1.063 IN |
| 9556 | M16-1.00 |
| 9557 | M10-1.00 |
| 9570 | Removable |
| 9568 | 1.063 IN |
| 9568 | 26.988 MM |
| 9567 | Open |
| 9566 | Bubble |
Additional Information
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | JP |
| UPC | 805890228790 |
Part Interchanges
Fits Vehicles
- Mitsubishi Lancer (2006)
