CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Misc Holes [cntrc] 1
Product Grade [cntrc] Standard
Disc Mounting [cntrc] Floating
Weight [cntrc] Kgs 10.450
Vane Style [cntrc] Straight
Weight [cntrc] Lbs 23.000
Discard Thickness 27.000 MM
Discard Thickness 1.063 IN
Nominal Thickness 30.000 MM
Nominal Thickness 1.181 IN
Overall Height 62.200 MM
Overall Height 2.449 IN
Outside Diameter 317.100 MM
Outside Diameter 12.484 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 79.000 MM
Center Hole Diameter 3.110 IN
Mounting Bolt Hole Circle Diameter 120.000 MM
Mounting Bolt Hole Circle Diameter 4.724 IN
Stud/Lug Hole Quantity 5
Stud/Lug Hole Diameter 0.591 IN
Stud/Lug Hole Diameter 15.000 MM

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
Country of Origin (Primary) CN
NAFTA Preference Criterion Code B
Harmonized Tariff Code (HTS) 8708305030
UPC 805890629429

Part Interchanges

CENTRIC 121.22013 Cross Reference

We have 1 alternatives for the 121.22013 by CENTRIC:

Fits Vehicles

  • Land Rover LR3 (2005-2009)
