Centric 125.34045 - Centric Premium High Carbon Alloy Brake Rotor
$8149
MSRP: $96.66
Save: $15.17
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
Product Attributes
| Weight [cntrc] Kgs | 7.850 |
| Weight [cntrc] Lbs | 17.280 |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 1 |
| Discard Thickness | 20.400 MM |
| Discard Thickness | 0.803 IN |
| Nominal Thickness | 0.866 IN |
| Nominal Thickness | 22.000 MM |
| Hat Finish | Coated |
| Overall Height | 76.000 MM |
| Overall Height | 2.992 IN |
| Outside Diameter | 296.000 MM |
| Outside Diameter | 11.654 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 3.110 IN |
| Center Hole Diameter | 79.000 MM |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.575 IN |
| Stud/Lug Hole Diameter | 14.600 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890203506 |
Part Interchanges
- Raybestos Brakes 96801FZN
- Raybestos Brakes 96801R
- Raybestos Brakes 96801
- BD125575
- BD125575E
- BD180108
- 422159
- 522159
- 6412480
- 34161
- 34121
- 34161G
- 34111163013
- 34111163081
- 34111164839
- 34116767061
- 145371
- 880195
- EBR496
- 125.34045
- 1.0636.2.4
- YH145371
- 25473
- 96801P
- DDF834
- DF2769
- 8962046
- 142101
- 90031043
- 150.1284.00
CENTRIC 125.34045 Cross Reference
We have 3 alternatives for the 125.34045 by CENTRIC:
Fits Vehicles
- BMW 525i (2001-2003)
- BMW 528i (1996-2000)
