Centric 123.66039 - C-Tek Standard Brake Drum
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Kgs | 10.909 |
| Weight [cntrc] Lbs | 24.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 165.100 |
| Bolt Circle Diameter [cntrc] In | 6.500 |
| Hub Hole / Register [cntrc] Mm | 116.840 |
| Hub Hole / Register [cntrc] In | 4.600 |
| Height [cntrc] Mm | 135.890 |
| Height [cntrc] In | 5.350 |
| Friction Surface Width [cntrc] Mm | 71.120 |
| Friction Surface Width [cntrc] In | 2.800 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 306.300 MM |
| Maximum Brake Diameter (Discard) | 12.060 IN |
| Bolt Hole Quantity | 8 |
| Outside Diameter | 355.092 MM |
| Outside Diameter | 13.980 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 13.462 MM |
| Mounting Hole Diameter | 0.530 IN |
| Nominal Drum Diameter | 304.800 MM |
| Nominal Drum Diameter | 12.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890305194 |
Part Interchanges
CENTRIC 123.66039 Cross Reference
We have 3 alternatives for the 123.66039 by CENTRIC:
Fits Vehicles
- Chevrolet C20 Panel (1967)
- GMC K15/K1500 Pickup (1966)
- GMC C25/C2500 Suburban (1968-1970)
- GMC K25/K2500 Pickup (1967-1970)
- GMC C25/C2500 Pickup (1967-1970)
- GMC 1500 Series (1964-1965)
- Chevrolet C20 Suburban (1968-1970)
- Chevrolet C20 Pickup (1964-1970)
