Centric 123.66016 - C-Tek Standard Brake Drum
$4599
MSRP: $50.93
Save: $4.94
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 6.955 |
| Weight [cntrc] Lbs | 15.300 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 127.000 |
| Bolt Circle Diameter [cntrc] In | 5.000 |
| Hub Hole / Register [cntrc] Mm | 78.740 |
| Hub Hole / Register [cntrc] In | 3.100 |
| Height [cntrc] Mm | 79.756 |
| Height [cntrc] In | 3.140 |
| Friction Surface Width [cntrc] Mm | 62.992 |
| Friction Surface Width [cntrc] In | 2.480 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 243.600 MM |
| Maximum Brake Diameter (Discard) | 9.590 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 303.022 MM |
| Outside Diameter | 11.930 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 13.462 MM |
| Mounting Hole Diameter | 0.530 IN |
| Nominal Drum Diameter | 241.300 MM |
| Nominal Drum Diameter | 9.500 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890052999 |
Part Interchanges
CENTRIC 123.66016 Cross Reference
We have 8 alternatives for the 123.66016 by CENTRIC:
Fits Vehicles
- GMC Safari (1985-2002)
- Chevrolet Astro (1985-2002)
