CENTRIC 123.62035 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 123.62035 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.795 |
| Weight [cntrc] Lbs | 12.750 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 56.896 |
| Hub Hole / Register [cntrc] In | 2.240 |
| Height [cntrc] Mm | 73.406 |
| Height [cntrc] In | 2.890 |
| Friction Surface Width [cntrc] Mm | 54.610 |
| Friction Surface Width [cntrc] In | 2.150 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 231.000 MM |
| Maximum Brake Diameter (Discard) | 9.094 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 271.018 MM |
| Outside Diameter | 10.670 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 13.720 MM |
| Mounting Hole Diameter | 0.540 IN |
| Nominal Drum Diameter | 229.200 MM |
| Nominal Drum Diameter | 9.024 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890492672 |
CENTRIC 123.62035 Cross References
CENTRIC 123.62035 Fits Vehicles
- Pontiac G4 (2005-2006)
- Pontiac G5 (2007-2008)
- Pontiac Pursuit (2005-2006)
- Saturn Ion (2003-2007)
- Chevrolet Cobalt (2005-2008)
