Centric 123.61032 - C-Tek Standard Brake Drum
$2599
MSRP: $32.69
Save: $6.70
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 3.636 |
| Weight [cntrc] Lbs | 8.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 107.950 |
| Bolt Circle Diameter [cntrc] In | 4.250 |
| Hub Hole / Register [cntrc] Mm | 66.040 |
| Hub Hole / Register [cntrc] In | 2.600 |
| Height [cntrc] Mm | 68.834 |
| Height [cntrc] In | 2.710 |
| Friction Surface Width [cntrc] Mm | 41.910 |
| Friction Surface Width [cntrc] In | 1.650 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 204.700 MM |
| Maximum Brake Diameter (Discard) | 8.060 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 235.966 MM |
| Outside Diameter | 9.290 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.224 MM |
| Mounting Hole Diameter | 0.560 IN |
| Nominal Drum Diameter | 203.000 MM |
| Nominal Drum Diameter | 7.992 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890052265 |
Part Interchanges
- 52-60696
- BD60696
- 5260696
- 8940
- BD8940
- 63 92 530
- 6392510
- 112692
- 8940G
- E63Z1126A
- E43Z1113A
- E43Z1113B
- 202401
- 140453
- PDR0453
- 6401440
- 6401446
- 440-1446
- 4401446
- 841
- AD8132
- AD8132E
- D2692
- 87277
- YH140453
- 23040
- X21666
- BD1459
- 102692
- 2692
- 2692DGS
- 2692R
- ZAD8132E
- 78834032
- 8834032
- 78-34032
- 7834032
- 68060
- 177332
- 36554028
CENTRIC 123.61032 Cross Reference
We have 4 alternatives for the 123.61032 by CENTRIC:
Fits Vehicles
- Mercury Topaz (1984-1994)
- Mercury Lynx (1985-1987)
- Ford Tempo (1984-1994)
- Ford Escort (1985-1990)
- Ford EXP (1985)
