(888) 312-8812 Login SignupCENTRIC 123.61001 C-Tek Standard Brake Drum
Tap to view 4 more
$4699
Limited availability at this price!
In Stock
Get it by Friday, Feb 6
CENTRIC 123.61001 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 123.61001 Specifications
Product Attributes
| Weight [cntrc] Kgs | 4.091 |
| Weight [cntrc] Lbs | 9.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 61.722 |
| Hub Hole / Register [cntrc] In | 2.430 |
| Height [cntrc] Mm | 59.690 |
| Height [cntrc] In | 2.350 |
| Friction Surface Width [cntrc] Mm | 46.736 |
| Friction Surface Width [cntrc] In | 1.840 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 230.900 MM |
| Maximum Brake Diameter (Discard) | 9.090 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 262.890 MM |
| Outside Diameter | 10.350 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 15.750 MM |
| Mounting Hole Diameter | 0.620 IN |
| Nominal Drum Diameter | 228.600 MM |
| Nominal Drum Diameter | 9.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Country of Origin (Primary) | CN |
| NAFTA Preference Criterion Code | B |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890052135 |
CENTRIC 123.61001 Cross References
| Brand | Part Number |
|---|---|
| 122.61001, F1EZ15K868W | |
| N/A | BD60064, E127-66-006, E128-66-006, 8147, BD8147, 123.61001, 63 92 630, 8147G, C0DD1126A, C0DZ1126A, C0DZ1126C, 140139, PDR0139, 202470, 6401068, 868, AD8101, AD8101E, D2641, E12766006, 87208, X21010, 23047, BD1102, 102641, 2641, 2641R, 2641DGS, 8834001, 7834001, 78834001, 78-34001, 36554005, 177 57 |
| PRONTO | BD8147 |
| RAYBESTOS | 2641, 2641R |
| WAGNER | BD60064 |
CENTRIC 123.61001 Fits Vehicles
- Mercury Cyclone (1964)
- Mercury Villager (1965)
- Mercury Comet (1960-1965, 1971-1972)
- Mercury Caliente (1964-1965)
- Ford Mustang (1964-1970)
- Ford Maverick (1970-1973)
- Ford Falcon Sedan Delivery (1961-1965)
- Ford Falcon (1960-1969)
