CENTRIC 123.46009 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 123.46009 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.000 |
| Weight [cntrc] Lbs | 11.000 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 67.000 |
| Hub Hole / Register [cntrc] In | 2.638 |
| Height [cntrc] Mm | 71.120 |
| Height [cntrc] In | 2.800 |
| Friction Surface Width [cntrc] Mm | 40.640 |
| Friction Surface Width [cntrc] In | 1.600 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 182.000 MM |
| Maximum Brake Diameter (Discard) | 7.165 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 216.000 MM |
| Outside Diameter | 8.504 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.000 MM |
| Mounting Hole Diameter | 0.551 IN |
| Nominal Drum Diameter | 180.000 MM |
| Nominal Drum Diameter | 7.087 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890052029 |
CENTRIC 123.46009 Cross References
| Brand | Part Number |
|---|---|
| 122.46009, F1EZ15K857C | |
| N/A | BD61954, 0832346, E128-51-014, E127-51-014, 3574, BD3574, 123.46009, 6382010, 63 82 010, 5271121320, 3574G, 100689, 140571, PDR0571, 224302, 6401638, 725, JBD334, JBD334E, D9387, E12751014, E12851014, 87477, X30748, BD1558, 9477DGS, 9477, 9477R, 78-16008, 7816008, 8816008, 78816008, 36503001 |
| RAYBESTOS | 9477, 9477R |
CENTRIC 123.46009 Fits Vehicles
- Mitsubishi Precis (1988-1989)
- Hyundai Excel (1988-1989)
