Centric 123.45015 - C-Tek Standard Brake Drum
$6449
MSRP: $71.05
Save: $6.56
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 4 |
| Weight [cntrc] Kgs | 9.886 |
| Weight [cntrc] Lbs | 21.750 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 92.710 |
| Hub Hole / Register [cntrc] In | 3.650 |
| Height [cntrc] Mm | 76.200 |
| Height [cntrc] In | 3.000 |
| Friction Surface Width [cntrc] Mm | 63.250 |
| Friction Surface Width [cntrc] In | 2.490 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 261.500 MM |
| Maximum Brake Diameter (Discard) | 10.295 IN |
| Bolt Hole Quantity | 6 |
| Outside Diameter | 311.000 MM |
| Outside Diameter | 12.244 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.300 MM |
| Mounting Hole Diameter | 0.484 IN |
| Nominal Drum Diameter | 260.000 MM |
| Nominal Drum Diameter | 10.236 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890076384 |
Part Interchanges
CENTRIC 123.45015 Cross Reference
We have 2 alternatives for the 123.45015 by CENTRIC:
Fits Vehicles
- Mazda B2600 (1987-1993)
