Centric 123.44026 - C-Tek Standard Brake Drum
$4749
MSRP: $52.62
Save: $5.13
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 7.045 |
| Weight [cntrc] Lbs | 15.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 60.000 |
| Hub Hole / Register [cntrc] In | 2.362 |
| Height [cntrc] Mm | 73.400 |
| Height [cntrc] In | 2.890 |
| Friction Surface Width [cntrc] Mm | 62.700 |
| Friction Surface Width [cntrc] In | 2.469 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 256.000 MM |
| Maximum Brake Diameter (Discard) | 10.079 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 303.200 MM |
| Outside Diameter | 11.937 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.400 MM |
| Mounting Hole Diameter | 0.567 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890051862 |
Part Interchanges
CENTRIC 123.44026 Cross Reference
We have 4 alternatives for the 123.44026 by CENTRIC:
Fits Vehicles
- Toyota Previa (1991-1997)
