(888) 312-8812 Login SignupCENTRIC 123.42008 C-Tek Standard Brake Drum
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 123.42008 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 123.42008 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.682 |
| Weight [cntrc] Lbs | 12.500 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Stud Thread Pitch [cntrc] Mm | 1.25 |
| Hub Hole / Register [cntrc] Mm | 60.700 |
| Hub Hole / Register [cntrc] In | 2.390 |
| Height [cntrc] Mm | 82.000 |
| Height [cntrc] In | 3.228 |
| Friction Surface Width [cntrc] Mm | 41.500 |
| Friction Surface Width [cntrc] In | 1.634 |
| Product Grade [cntrc] | Standard |
| Stud Thread Size | 12 MM |
| Maximum Brake Diameter (Discard) | 204.500 MM |
| Maximum Brake Diameter (Discard) | 8.051 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 236.000 MM |
| Outside Diameter | 9.291 IN |
| Outer Cooling Fins | No |
| Nominal Drum Diameter | 203.200 MM |
| Nominal Drum Diameter | 8.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890051657 |
CENTRIC 123.42008 Cross References
| Brand | Part Number |
|---|---|
| 122.42008, F1EZ14632EB | |
| N/A | 0832238, BD60752, 3511, 123.42008, 6376390, 63 76 390, 4320204R04, 3511G, 371, 4320204A00, 4320204A01, 4320204R00, 4320216R00, 100260, 140476, PDR0476, 209110, 6401525, 975, JBD151, JBD151E, D9376, 87290, 87500, X21723, 21058, BD1480, 9500, 9527, 9527R, 9527DGS, 78804008, 78-04008, 7804008, 8804008, 36567008 |
| RAYBESTOS | 9527, 9527R |
CENTRIC 123.42008 Fits Vehicles
- Nissan Pulsar NX (1983-1986)
- Nissan Sentra (1983-1985)
