Centric 123.33003 - C-Tek Standard Brake Drum
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Notes [cntrc] | Splined |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 5.682 |
| Weight [cntrc] Lbs | 12.500 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 196.850 |
| Bolt Circle Diameter [cntrc] In | 7.750 |
| Stud Thread Pitch [cntrc] Mm | 1.50 |
| Hub Hole / Register [cntrc] Mm | 153.000 |
| Hub Hole / Register [cntrc] In | 6.024 |
| Height [cntrc] Mm | 82.000 |
| Height [cntrc] In | 3.228 |
| Friction Surface Width [cntrc] Mm | 43.500 |
| Friction Surface Width [cntrc] In | 1.713 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 231.000 MM |
| Maximum Brake Diameter (Discard) | 9.094 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 262.000 MM |
| Outside Diameter | 10.315 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.000 MM |
| Nominal Drum Diameter | 230.000 MM |
| Nominal Drum Diameter | 9.055 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890140344 |
Part Interchanges
CENTRIC 123.33003 Cross Reference
We have 4 alternatives for the 123.33003 by CENTRIC:
Fits Vehicles
- Volkswagen Karmann Ghia (1958-1972)
- Volkswagen Beetle (1958-1967)
