Name: Centric 122.65038 Centric Premium Brake Drum
SKU: 12265038
Price: 76.99 USD
Availability: InStock

CENTRIC part description

Product Description

Centric Premium Brake Drum

Features & Benefits

OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise

Product Attributes

Weight [cntrc] Kgs	8.409
Weight [cntrc] Lbs	18.500
Mounting Type [cntrc]	Floating
Bolt Circle Diameter [cntrc] Mm	135.000
Bolt Circle Diameter [cntrc] In	5.310
Hub Hole / Register [cntrc] Mm	87.376
Hub Hole / Register [cntrc] In	3.440
Height [cntrc] Mm	93.980
Height [cntrc] In	3.700
Friction Surface Width [cntrc] Mm	68.580
Friction Surface Width [cntrc] In	2.700
Product Grade [cntrc]	Premium
Maximum Brake Diameter (Discard)	282.400 MM
Maximum Brake Diameter (Discard)	11.118 IN
Bolt Hole Quantity	5
Outside Diameter	323.596 MM
Outside Diameter	12.740 IN
Outer Cooling Fins	No
Mounting Hole Diameter	14.224 MM
Mounting Hole Diameter	0.560 IN
Nominal Drum Diameter	279.400 MM
Nominal Drum Diameter	11.000 IN

Additional Information

Harmonized Tariff Code (Schedule B)	8708300050
Harmonized Tariff Code (HTS)	8708305030
NAFTA Preference Criterion Code	B
Country of Origin (Primary)	CN
UPC	805890038351

Part Interchanges

CENTRIC 122.65038 Cross Reference

We have 4 alternatives for the 122.65038 by CENTRIC:

Fits Vehicles

Ford F-150 (1997-2000)
