CENTRIC 122.63048 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
CENTRIC 122.63048 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.432 |
| Weight [cntrc] Lbs | 11.950 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 80.000 |
| Hub Hole / Register [cntrc] In | 3.149 |
| Height [cntrc] Mm | 60.198 |
| Height [cntrc] In | 2.370 |
| Friction Surface Width [cntrc] Mm | 46.200 |
| Friction Surface Width [cntrc] In | 1.819 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 230.600 MM |
| Maximum Brake Diameter (Discard) | 9.079 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 268.200 MM |
| Outside Diameter | 10.559 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.700 MM |
| Mounting Hole Diameter | 0.500 IN |
| Nominal Drum Diameter | 228.500 MM |
| Nominal Drum Diameter | 8.996 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890299134 |
CENTRIC 122.63048 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 9782R |
| N/A | BD126480, E127-68-053, YH200367, 23098, 1408-75799, 23098G, 5105617AB, 9782, 860009, 36542009, E12768053 |
CENTRIC 122.63048 Fits Vehicles
- Jeep Compass (2009-2017)
- Jeep Patriot (2008-2017)
- Dodge Avenger (2008-2009)
- Chrysler Sebring (2007-2009)
- Dodge Caliber (2007-2011)
CENTRIC 122.63048 Cross References
We have 3 alternatives for the 122.63048 by CENTRIC:
