Quality-Built Disc Brake Rotor - Black Series, Coated

Product Description

Quality-Built Black Series Coated Rotor

Application Summary

Lexus LS460 2017-2007, LS500 2022-2018, LS500h 2022-2018, LS600h 2016-2008

Features & Benefits

  • OE Style Symmetric Vane Designs
  • Non-directional friction surfaces
  • Precision machined mounting surfaces
  • Installation-ready without cleaning
  • Q-Shield Protective Coatings
  • High-Carbon Metullargy
  • G11H18 Alloys
  • Mill balanced
  • Straddle Cut to eliminate DTV

Black Series Brake Rotor, Brake Rotor, MPA Brake Rotot, Quality-Built Brake Rotor, Coated Rotor, Black Coated Rotor

Product Attributes

Finish Coated
Product Condition New
Discard Thickness 31.0 MM
Discard Thickness 1.2 IN
Nominal Thickness 34.0 MM
Nominal Thickness 1.3 IN
Disc Finish Coated
Hat Finish Coated
Rust Resistant Coating Yes
Outside Diameter 357.0 MM
Outside Diameter 14.1 IN
Grade Type Regular
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 62.0 MM
Mounting Bolt Hole Circle Diameter 120.0 MM
Mounting Bolt Hole Circle Diameter 4.724 IN
Mounting Bolt Hole Diameter 0.650 IN
Mounting Bolt Hole Diameter 16.5 MM
Stud/Lug Hole Quantity 5

Additional Information

Harmonized Tariff Code (HTS) 8708305030
Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 00190037433787

Fits Vehicles

  • Lexus LS500 (2018-2022)
  • Lexus LS500h (2018-2022)
  • Lexus LS600h (2008-2016)
  • Lexus LS460 (2007-2017)
