MPA Electrical BR31296G - Quality-Built Disc Brake Rotor - Black Series, Coated
- Part Number
- BR31296G
- Manufacturer
- MPA ELECTRICAL
- Description
-
Quality-Built Disc Brake Rotor - Black Series, Coated
details
$8599
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
MPA ELECTRICAL part description
Quality-Built Disc Brake Rotor - Black Series, Coated
Product Description
Quality-Built Black Series Coated Rotor
Application Summary
Chevrolet LCF 3500 2018-2016, LCF 4500HD 2019-2017, W4500 Tiltmaster 2008-1999, GMC W4500 Forward 2009-1999, Isuzu NPR 2017-1998, NPR-HD 2018-1999
Features & Benefits
- OE Style Symmetric Vane Designs
- Non-directional friction surfaces
- Precision machined mounting surfaces
- Installation-ready without cleaning
- Q-Shield Protective Coatings
- High-Carbon Metullargy
- G11H18 Alloys
- Mill balanced
- Straddle Cut to eliminate DTV
Black Series Brake Rotor, Brake Rotor, MPA Brake Rotot, Quality-Built Brake Rotor, Coated Rotor, Black Coated Rotor
Product Attributes
| Product Condition | New |
| Finish | Coated |
| Discard Thickness | 37.0 MM |
| Discard Thickness | 1.5 IN |
| Nominal Thickness | 40.0 MM |
| Nominal Thickness | 1.6 IN |
| Disc Finish | Coated |
| Hat Finish | Coated |
| Rust Resistant Coating | Yes |
| Outside Diameter | 293.0 MM |
| Outside Diameter | 11.5 IN |
| Grade Type | Regular |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 110.0 MM |
| Mounting Bolt Hole Circle Diameter | 136.0 MM |
| Mounting Bolt Hole Circle Diameter | 5.354 IN |
| Mounting Bolt Hole Diameter | 0.492 IN |
| Mounting Bolt Hole Diameter | 12.5 MM |
| Stud/Lug Hole Quantity | 12 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00190037430519 |
Fits Vehicles
- Chevrolet LCF 3500 (2016-2018)
- Chevrolet LCF 4500HD (2017-2019)
- Isuzu NPR-HD (1999-2018)
- Isuzu NPR (1998-2017)
- Chevrolet W4500 Tiltmaster (1999-2008)
- GMC W4500 Forward (1999-2009)
