(888) 312-8812 Login SignupCENTRIC 122.61015 Centric Premium Brake Drum
Tap to view 3 more
*Representative image - actual part not displayed
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 122.61015 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.61015 Specifications
Product Attributes
| Weight [cntrc] Kgs | 8.114 |
| Weight [cntrc] Lbs | 17.850 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 70.612 |
| Hub Hole / Register [cntrc] In | 2.780 |
| Height [cntrc] Mm | 83.566 |
| Height [cntrc] In | 3.290 |
| Friction Surface Width [cntrc] Mm | 70.612 |
| Friction Surface Width [cntrc] In | 2.780 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 256.300 MM |
| Maximum Brake Diameter (Discard) | 10.090 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 314.960 MM |
| Outside Diameter | 12.400 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 15.240 MM |
| Mounting Hole Diameter | 0.600 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890037682 |
CENTRIC 122.61015 Cross References
CENTRIC 122.61015 Fits Vehicles
- Mercury Comet (1974-1975)
- Ford Maverick (1974-1975)
