CENTRIC 122.51012 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
CENTRIC 122.51012 Specifications
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 4.318 |
| Weight [cntrc] Lbs | 9.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 76.000 |
| Hub Hole / Register [cntrc] In | 2.992 |
| Height [cntrc] Mm | 59.000 |
| Height [cntrc] In | 2.323 |
| Friction Surface Width [cntrc] Mm | 44.300 |
| Friction Surface Width [cntrc] In | 1.744 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 205.200 MM |
| Maximum Brake Diameter (Discard) | 7.070 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 242.000 MM |
| Outside Diameter | 9.528 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.300 MM |
| Mounting Hole Diameter | 0.484 IN |
| Nominal Drum Diameter | 202.700 MM |
| Nominal Drum Diameter | 7.980 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890196150 |
CENTRIC 122.51012 Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 9754, 9754R |
| N/A | BD126142, 5841117, 5841117100, 5841117XXX, YH140791, 35104, 21132, 35104G, 5841117200, 140791, 36503015 |
CENTRIC 122.51012 Fits Vehicles
- Hyundai Elantra (2002-2006)
CENTRIC 122.51012 Cross References
We have 4 alternatives for the 122.51012 by CENTRIC:
