CENTRIC 122.49003 Part Description
Manufacturer
Product Description
Centric Premium Brake Drum
Features & Benefits
- OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise
CENTRIC 122.49003 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.000 |
| Weight [cntrc] Lbs | 11.000 |
| Mounting Type [cntrc] | Hub & Drum |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Stud Thread Pitch [cntrc] Mm | 1.50 |
| Hub Hole / Register [cntrc] Mm | 56.400 |
| Hub Hole / Register [cntrc] In | 2.220 |
| Height [cntrc] Mm | 75.000 |
| Height [cntrc] In | 2.953 |
| Friction Surface Width [cntrc] Mm | 40.500 |
| Friction Surface Width [cntrc] In | 1.594 |
| Product Grade [cntrc] | Premium |
| Stud Thread Size | 12 MM |
| Maximum Brake Diameter (Discard) | 201.000 MM |
| Maximum Brake Diameter (Discard) | 7.913 IN |
| Nominal Drum Diameter | 7.874 IN |
| Nominal Drum Diameter | 200.000 MM |
| Outer Cooling Fins | No |
| Outside Diameter | 9.055 IN |
| Outside Diameter | 230.000 MM |
| Bolt Hole Quantity | 4 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890313403 |
CENTRIC 122.49003 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | BD126287, BD920188, 920188, 80115, 36547005, 123.49003, 96386900 |
CENTRIC 122.49003 Fits Vehicles
- Pontiac Wave5 (2005)
- Chevrolet Aveo5 (2006)
- Pontiac Wave (2005-2006)
- Chevrolet Aveo (2004-2006)
CENTRIC 122.49003 Cross References
We have 2 alternatives for the 122.49003 by CENTRIC:
