MPA ELECTRICAL part description

Quality-Built Disc Brake Rotor - Black Series, Coated

Product Description

Quality-Built Black Series Coated Rotor

Application Summary

Ford Fusion 2012-2006, Lincoln MKZ 2012-2007, Zephyr 2006, Mazda 6 2013-2003, 626 2002-1998, MX-5 Miata 2015-2006, Protege 2003, Mercury Milan 2011-2006

Features & Benefits

  • OE Style Symmetric Vane Designs
  • Non-directional friction surfaces
  • Precision machined mounting surfaces
  • Installation-ready without cleaning
  • Q-Shield Protective Coatings
  • High-Carbon Metullargy
  • G11H18 Alloys
  • Mill balanced
  • Straddle Cut to eliminate DTV

Black Series Brake Rotor, Brake Rotor, MPA Brake Rotot, Quality-Built Brake Rotor, Coated Rotor, Black Coated Rotor

Product Attributes

Product Condition New
Finish Coated
Discard Thickness 8.0 MM
Discard Thickness 0.3 IN
Nominal Thickness 10.0 MM
Nominal Thickness 0.4 IN
Disc Finish Coated
Hat Finish Coated
Rust Resistant Coating Yes
Outside Diameter 280.0 MM
Outside Diameter 11.0 IN
Grade Type Regular
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Solid
Bearings Included No
Center Hole Diameter 71.7 MM
Mounting Bolt Hole Circle Diameter 114.3 MM
Mounting Bolt Hole Circle Diameter 4.500 IN
Mounting Bolt Hole Diameter 0.512 IN
Mounting Bolt Hole Diameter 13.0 MM
Stud/Lug Hole Quantity 5

Additional Information

Harmonized Tariff Code (HTS) 8708305030
Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 00190037244277

Fits Vehicles

  • Lincoln MKZ (2007-2012)
  • Mazda MX-5 Miata (2006-2015)
  • Lincoln Zephyr (2006)
  • Mercury Milan (2006-2011)
  • Ford Fusion (2006-2012)
  • Mazda 626 (1998-2002)
  • Mazda Protege (2003)
  • Mazda 6 (2003-2013)
