(888) 312-8812 Login SignupCentric Premium Brake Drum
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 11.136 |
| Weight [cntrc] Lbs | 24.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 62.000 |
| Hub Hole / Register [cntrc] In | 2.441 |
| Height [cntrc] Mm | 73.600 |
| Height [cntrc] In | 2.898 |
| Friction Surface Width [cntrc] Mm | 61.600 |
| Friction Surface Width [cntrc] In | 2.425 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 256.000 MM |
| Maximum Brake Diameter (Discard) | 10.079 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 306.000 MM |
| Outside Diameter | 12.047 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.500 MM |
| Mounting Hole Diameter | 0.571 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890196099 |
| Brand | Part Number |
|---|---|
| 9753, BD126230 | |
| N/A | BD126230, E127-49-049, 35106, 24192, 1408-91694, 35070, 35106G, 24192G, 4243104050, 4243104051, 4243108020, 4243108021, 9753, 9778, 140790, 860002, 36576041, E12749049 |
| RAYBESTOS | 9778R |
| Raybestos Brakes | 9778R |
| WAGNER | BD126230, BD126330, BD126230E, BD126311 |
