Name: Centric 122.43005 Centric Premium Brake Drum
SKU: 12243005
Price: 69.49 USD
Availability: InStock

CENTRIC part description

Product Description

Centric Premium Brake Drum

Features & Benefits

OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise

Product Attributes

Weight [cntrc] Kgs	9.318
Weight [cntrc] Lbs	20.500
Mounting Type [cntrc]	Floating
Bolt Circle Diameter [cntrc] Mm	139.700
Bolt Circle Diameter [cntrc] In	5.500
Hub Hole / Register [cntrc] Mm	96.570
Hub Hole / Register [cntrc] In	3.802
Height [cntrc] Mm	80.510
Height [cntrc] In	3.170
Friction Surface Width [cntrc] Mm	60.960
Friction Surface Width [cntrc] In	2.400
Product Grade [cntrc]	Premium
Maximum Brake Diameter (Discard)	296.500 MM
Maximum Brake Diameter (Discard)	11.673 IN
Bolt Hole Quantity	6
Outside Diameter	335.280 MM
Outside Diameter	13.200 IN
Outer Cooling Fins	No
Mounting Hole Diameter	12.500 MM
Mounting Hole Diameter	0.492 IN
Nominal Drum Diameter	295.000 MM
Nominal Drum Diameter	11.614 IN

Additional Information

Harmonized Tariff Code (HTS)	8708305030
Harmonized Tariff Code (Schedule B)	8708300050
NAFTA Preference Criterion Code	B
Country of Origin (Primary)	CN
UPC	805890037187

Part Interchanges

CENTRIC 122.43005 Cross Reference

We have 4 alternatives for the 122.43005 by CENTRIC:

Fits Vehicles

Honda Passport (1998-1999)
Isuzu Rodeo (1998-1999)
Isuzu Amigo (1998-1999)
