CENTRIC part description

Product Description

Centric Premium Brake Drum

Features & Benefits

  • OE style castings ensure superior performance and extended service life. Machined finishes provide cleaner appearance through wheels. Precision machined friction surfaces ensure smooth operation and reduced noise

Product Attributes

Misc Holes [cntrc] 2
Weight [cntrc] Kgs 4.409
Weight [cntrc] Lbs 9.700
Mounting Type [cntrc] Floating
Bolt Circle Diameter [cntrc] Mm 114.300
Bolt Circle Diameter [cntrc] In 4.500
Hub Hole / Register [cntrc] Mm 68.000
Hub Hole / Register [cntrc] In 2.677
Height [cntrc] Mm 62.500
Height [cntrc] In 2.461
Friction Surface Width [cntrc] Mm 51.500
Friction Surface Width [cntrc] In 2.028
Product Grade [cntrc] Premium
Maximum Brake Diameter (Discard) 230.000 MM
Maximum Brake Diameter (Discard) 9.055 IN
Bolt Hole Quantity 4
Outside Diameter 266.000 MM
Outside Diameter 10.472 IN
Outer Cooling Fins No
Mounting Hole Diameter 12.600 MM
Mounting Hole Diameter 0.496 IN
Nominal Drum Diameter 228.500 MM
Nominal Drum Diameter 8.996 IN

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
Harmonized Tariff Code (HTS) 8708305030
UPC 805890032144

Part Interchanges

CENTRIC 122.42001 Cross Reference

We have 5 alternatives for the 122.42001 by CENTRIC:

Fits Vehicles

  • Nissan Ichi Van (1987-1994)
  • Nissan Maxima (1981-1984)
  • Nissan 710 (1974-1977)
  • Nissan Axxess (1990-1995)
  • Nissan Stanza (1987-1988, 1990-1992)
  • Nissan Altima (1993-2001)
  • Nissan 810 (1977-1981)
  • Nissan 610 (1973-1976)
  • Nissan 510 (1968-1973, 1978-1981)
  • Nissan 200SX (1977-1979, 1984)
