Centric 121.66027 - C-Tek Standard Brake Rotor
$10199
MSRP: $128.76
Save: $26.77
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Inner Bearing # [cntrc] | 410.91035 |
| Product Grade [cntrc] | Standard |
| Outer Bearing # [cntrc] | 415.66000 |
| Inner Seal # [cntrc] | 417.66000 |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Hub & Rotor |
| Weight [cntrc] Lbs | 37.000 |
| Misc Holes [cntrc] | 0 |
| Outer Race # [cntrc] | 416.66000 |
| Weight [cntrc] Kgs | 16.820 |
| Discard Thickness | 30.860 MM |
| Discard Thickness | 1.215 IN |
| Nominal Thickness | 32.700 MM |
| Nominal Thickness | 1.287 IN |
| Stud Thread Diameter | 14.000 MM |
| Overall Height | 126.100 MM |
| Overall Height | 4.965 IN |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| 54 | 317.200 MM |
| Rotor Outside Diameter | 12.488 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 1.500 MM |
| Bearings Included | No |
| Center Hole Diameter | 116.600 MM |
| Center Hole Diameter | 4.591 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Stud/Lug Hole Quantity | 8 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890051060 |
Part Interchanges
- BD125212
- 52-125212
- 52125212
- E126-71-032
- 5598
- BR5598
- R93 480
- 107251
- 5598G
- 15649969
- 15659250
- 15712781
- 15721421
- 15981318
- 15981319
- 141818
- PRT1818
- 101980
- 101980E
- 86263
- 311
- AR8627E
- D17598
- E12671032
- 27081
- X50657
- BR1906
- 1056263
- 56263
- 56263R
- 56263RGS
- ZAR8627
- 19775
- 7844027
- 78-44027
- 78944027
- 65690
- 18A507
- 177813
- 60048023
CENTRIC 121.66027 Cross Reference
We have 9 alternatives for the 121.66027 by CENTRIC:
Fits Vehicles
- Chevrolet G30 (1996)
- Chevrolet Express 3500 (1996-2001)
- Chevrolet Express 2500 (1996-2002)
- Chevrolet C3500 (1995-2000)
- Chevrolet C2500 Suburban (1992-1999)
- Chevrolet C2500 (1995-2000)
- Chevrolet C1500 Suburban (1994-1999)
- GMC Savana 3500 (1996-2001)
- GMC G3500 (1996)
- GMC C3500HD (1995-1996)
- GMC Savana 2500 (1996-2002)
- GMC C3500 (1995-2000)
- GMC C2500 Suburban (1992-1999)
- GMC C2500 (1996-2000)
- GMC C1500 Suburban (1994-1999)
