Centric 121.66017 - C-Tek Standard Brake Rotor
$4999
MSRP: $61.28
Save: $11.29
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Product Grade [cntrc] | Standard |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Inner Seal # [cntrc] | 417.66004 |
| Vane Style [cntrc] | Straight |
| Outer Bearing # [cntrc] | 410.91034 |
| Weight [cntrc] Kgs | 9.320 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Weight [cntrc] Lbs | 20.500 |
| Inner Bearing # [cntrc] | 410.91006 |
| Misc Holes [cntrc] | 0 |
| Discard Thickness | 24.500 MM |
| Discard Thickness | 0.965 IN |
| Nominal Thickness | 26.300 MM |
| Nominal Thickness | 1.035 IN |
| Stud Thread Diameter | 12.000 MM |
| Overall Height | 109.500 MM |
| Overall Height | 4.311 IN |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| 54 | 266.000 MM |
| Rotor Outside Diameter | 10.472 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 1.500 MM |
| Bearings Included | No |
| Center Hole Diameter | 72.000 MM |
| Center Hole Diameter | 2.835 IN |
| Mounting Bolt Hole Circle Diameter | 120.700 MM |
| Mounting Bolt Hole Circle Diameter | 4.752 IN |
| Stud/Lug Hole Quantity | 5 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890050995 |
Part Interchanges
- 52-125172
- 52125172
- BD125172
- E126-71-022
- 5575
- 31254
- BR5575
- BR31254
- R93 710
- 63610
- 5575G
- 31254G
- 107229
- 15725351
- 8156025740
- 8157253510
- 18060217
- 15602574
- 101601
- 101750
- PRT1631
- PRT5241
- 141631
- 145241
- 86137
- 618
- AR8617E
- D17526
- E12671022
- 31254HC
- 86757
- X50504
- 27039
- BR1895
- 1056137
- 1056757
- 56137
- 56137R
- 56137RGS
- 56757
- 56757R
- ZAR8617
- 19781
- 65495
- 60048016
- 177799
CENTRIC 121.66017 Cross Reference
We have 9 alternatives for the 121.66017 by CENTRIC:
Fits Vehicles
- GMC Sonoma (1991, 1994-2003)
- GMC Jimmy (1992-1997)
- GMC S15 Jimmy (1991)
- Isuzu Hombre (1996-2000)
- Chevrolet S10 (1994-2003)
- Chevrolet Blazer (1995-1997)
- Chevrolet S10 Blazer (1991-1994)
