Centric 121.66005 - C-Tek Standard Brake Rotor
$9549
MSRP: $116.78
Save: $21.29
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Outer Race # [cntrc] | 416.66000 |
| Weight [cntrc] Lbs | 38.600 |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Standard |
| Inner Bearing # [cntrc] | 410.91035 |
| Vane Style [cntrc] | Straight |
| Disc Mounting [cntrc] | Hub & Rotor |
| Inner Seal # [cntrc] | 417.66000 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Outer Bearing # [cntrc] | 415.66000 |
| Weight [cntrc] Kgs | 17.550 |
| Discard Thickness | 30.860 MM |
| Discard Thickness | 1.215 IN |
| Nominal Thickness | 32.800 MM |
| Nominal Thickness | 1.291 IN |
| Stud Thread Diameter | 0.563 IN |
| Overall Height | 121.000 MM |
| Overall Height | 4.764 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| 54 | 317.500 MM |
| Rotor Outside Diameter | 12.500 in |
| Stud/Lug Hole Quantity | 8 |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Center Hole Diameter | 4.591 IN |
| Center Hole Diameter | 116.600 MM |
| Bearings Included | No |
| Bolt Thread Pitch | 18.000 IN |
| Solid Or Vented Type Rotor | Vented |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Country of Origin (Primary) | CN |
| NAFTA Preference Criterion Code | B |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 805890050889 |
Part Interchanges
- 52-60402
- BD60402
- BD125330
- 5260402
- E126-71-010
- E125-71-010
- 5535
- BR5535
- R93 740
- 64 93 740
- 5518
- 107221
- 5535G
- 15641577
- 15674408
- 14012952
- 18001433
- 18008456
- 3990928
- 141186
- 141939
- PRT1186
- 101350
- 85679
- 4885679
- 517
- AR8605
- AR8605E
- D5010
- E8405
- E12571010
- E12671010
- 5535DSR
- 210098
- 210098C
- 55358
- 5535DSL
- 27057
- X50216
- BR1009
- 105010
- 105010R
- 5010
- 5010R
- 5010RGS
- 7844005
- 78944005
- 8944005
- 78-44005
- 65245
- 177613
- 60048004
CENTRIC 121.66005 Cross Reference
We have 22 alternatives for the 121.66005 by CENTRIC:
Fits Vehicles
- Chevrolet P30 (1975-1995)
- Chevrolet P20 (1975-1989)
- Chevrolet P30 Van (1971-1974)
- Chevrolet P20 Van (1971-1974)
- Chevrolet G30 Van (1971-1974)
- Chevrolet C30 Pickup (1971-1974)
- Chevrolet C20 Pickup (1971-1974)
- Chevrolet G30 (1975-1992)
- Chevrolet C30 (1975-1980)
- Chevrolet C20 Suburban (1971-1986)
- Chevrolet C20 (1975-1986)
- GMC R2500 Suburban (1987-1991)
- GMC R2500 (1987-1989)
- GMC P3500 (1979-1995)
- GMC P35 (1975-1978)
- GMC P2500 (1979-1989)
- GMC P25 (1975-1978)
- GMC G3500 (1979-1992)
- GMC G35 (1975-1978)
- GMC C3500 (1979-1980)
- GMC C35 (1975-1978)
- GMC C2500 Suburban (1979-1986)
- GMC C25 Suburban (1975-1978)
- GMC C2500 (1979-1986)
- GMC C25 (1975-1978)
- GMC P35/P3500 Van (1971-1974)
- GMC P25/P2500 Van (1971-1974)
- GMC G35/G3500 Van (1971-1974)
- GMC C35/C3500 Pickup (1971-1974)
- GMC C25/C2500 Suburban (1971-1974)
- GMC C25/C2500 Pickup (1971-1974)
- Chevrolet R2500 Suburban (1989-1991)
- Chevrolet R2500 (1989)
- Chevrolet R20 Suburban (1987-1988)
- Chevrolet R20 (1987-1988)
