Centric 121.66004 - C-Tek Standard Brake Rotor
$6199
MSRP: $75.72
Save: $13.73
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Disc Mounting [cntrc] | Behind the Hub |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Kgs | 12.950 |
| Weight [cntrc] Lbs | 28.500 |
| Product Grade [cntrc] | Standard |
| Mounting Bolt Hole Diameter | 0.587 IN |
| Mounting Bolt Hole Diameter | 14.900 MM |
| Mounting Bolt Hole Circle Diameter | 165.100 MM |
| Mounting Bolt Hole Circle Diameter | 6.500 IN |
| Center Hole Diameter | 127.200 MM |
| Center Hole Diameter | 5.008 IN |
| Bearings Included | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Mounting Bolt Hole Quantity | 8 |
| Outside Diameter | 12.870 IN |
| Outside Diameter | 326.900 MM |
| Overall Height | 3.079 IN |
| Overall Height | 78.200 MM |
| Nominal Thickness | 1.535 IN |
| Nominal Thickness | 38.990 MM |
| Discard Thickness | 37.210 MM |
| Discard Thickness | 1.465 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890140092 |
Part Interchanges
- 52-60597
- BD60597
- 5260597
- E126-71-009
- E125-71-009
- 5564
- BR5564
- 6493430
- 5564G
- 12361507
- 12361508
- 12385855
- 12385856
- 4506132
- 15622381
- 15635678
- 15649274
- 15983003
- 14039119
- 462825
- 475986
- 141468
- PRT1468
- 101640
- 85822
- 4885822
- 624
- AR8604
- AR8604E
- D17301
- E12571009
- E12671009
- E8407
- E8445
- 5564GT
- 100353
- 100353G
- 210299
- 210299C
- 27275
- X50360
- BR1375
- 5046
- 5046R
- 8944004
- 78944004
- 60048003
- 177704
CENTRIC 121.66004 Cross Reference
We have 5 alternatives for the 121.66004 by CENTRIC:
Fits Vehicles
- Chevrolet K3500 (1990-2000)
- Chevrolet K30 (1977-1986)
- Dodge W350 (1990-1993)
- GMC V3500 (1987-1991)
- GMC K3500 (1979-1986, 1990-2000)
- GMC K35 (1977-1978)
- Chevrolet V3500 (1989-1991)
- Chevrolet V30 (1987-1988)
