CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Disc Mounting [cntrc] Floating
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Weight [cntrc] Kgs 3.640
Vane Style [cntrc] Straight
Misc Holes [cntrc] 0
Weight [cntrc] Lbs 8.000
Product Grade [cntrc] Standard
Discard Thickness 0.724 IN
Discard Thickness 18.400 MM
Nominal Thickness 20.000 MM
Nominal Thickness 0.787 IN
Overall Height 38.400 MM
Overall Height 1.512 IN
Outside Diameter 239.300 MM
Outside Diameter 9.421 IN
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 61.000 MM
Center Hole Diameter 2.402 IN
Mounting Bolt Hole Circle Diameter 100.000 MM
Mounting Bolt Hole Circle Diameter 3.937 IN
Stud/Lug Hole Quantity 4
Stud/Lug Hole Diameter 0.555 IN
Stud/Lug Hole Diameter 14.100 MM

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890050247

Part Interchanges

CENTRIC 121.63038 Cross Reference

We have 8 alternatives for the 121.63038 by CENTRIC:

Fits Vehicles

  • Dodge Neon (1995-1996)
  • Plymouth Neon (1995)
