CENTRIC part description

Product Description

C-Tek Standard Brake Rotor

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Disc Mounting [cntrc] Behind the Hub
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Weight [cntrc] Kgs 5.680
Vane Style [cntrc] Straight
Misc Holes [cntrc] 0
Weight [cntrc] Lbs 12.500
Product Grade [cntrc] Standard
Discard Thickness 0.790 IN
Discard Thickness 20.070 MM
Nominal Thickness 20.570 MM
Nominal Thickness 0.810 IN
Overall Height 57.800 MM
Overall Height 2.276 IN
Outside Diameter 280.400 MM
Outside Diameter 11.039 IN
Mounting Bolt Hole Quantity 5
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 73.800 MM
Center Hole Diameter 2.906 IN
Mounting Bolt Hole Circle Diameter 4.000 IN
Mounting Bolt Hole Circle Diameter 101.600 MM
Mounting Bolt Hole Diameter 15.900 MM
Mounting Bolt Hole Diameter 0.626 IN

Additional Information

Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
Harmonized Tariff Code (Schedule B) 8708300050
UPC 805890351405

Part Interchanges

CENTRIC 121.63005 Cross Reference

We have 2 alternatives for the 121.63005 by CENTRIC:

Fits Vehicles

  • Dodge Dart (1967-1972)
  • Plymouth Valiant (1965-1972)
  • Plymouth Scamp (1971-1972)
  • Plymouth Duster (1970-1972)
  • Plymouth Barracuda (1969)
