(888) 312-8812 Login SignupCENTRIC 121.61003 C-Tek Standard Brake Rotor
Tap to view 4 more
$10199
Limited availability at this price!
In Stock
Get it by Thursday, Jan 8
CENTRIC 121.61003 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 121.61003 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Vane Style [cntrc] | Straight |
| Inner Seal # [cntrc] | 417.61000 |
| Misc Holes [cntrc] | 0 |
| Product Grade [cntrc] | Standard |
| Outer Bearing # [cntrc] | 410.91012 |
| Inner Bearing # [cntrc] | 410.91013 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Weight [cntrc] Lbs | 26.200 |
| Weight [cntrc] Kgs | 11.910 |
| Discard Thickness | 28.450 MM |
| Discard Thickness | 1.120 IN |
| Nominal Thickness | 30.100 MM |
| Nominal Thickness | 1.185 IN |
| Stud Thread Diameter | 0.500 IN |
| Overall Height | 114.900 MM |
| Overall Height | 4.524 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Rotor Outside Diameter | 297.700 MM |
| Rotor Outside Diameter | 11.720 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 70.500 MM |
| Center Hole Diameter | 2.776 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890139799 |
CENTRIC 121.61003 Part Interchanges
| Brand | Part Number |
|---|---|
| N/A | BD60214, E126-66-008, 5405, 121.61003, 5405G, D0AZ1102A, D1VY1102A, D1VY2140A, PRT1016, 141016, 102050, 85534, 4885534, 407, AR8103, AR8103E, D6014, E12666008, 210020, 210020C, X50035, BR1033, 6014, 6014R, 78934003, 8934003, 60054009, 177539 |
CENTRIC 121.61003 Fits Vehicles
- Ford LTD (1970-1972)
- Ford Galaxie 500 (1970-1972)
- Ford Custom 500 (1971-1972)
- Ford Country Squire (1971-1972)
- Ford Country Sedan (1971-1972)
- Ford Custom (1971-1972)
- Mercury Monterey (1970-1972)
- Mercury Marquis (1970-1972)
- Mercury Marauder (1970)
- Mercury Colony Park (1970-1972)
- Lincoln Mark III (1970-1971)
- Lincoln Continental (1970-1972)
- Ford Thunderbird (1970-1971)
- Ford Ranch Wagon (1970-1972)
CENTRIC 121.61003 Cross References
We have 4 alternatives for the 121.61003 by CENTRIC:
